If you're looking for a particularly natural-looking LED light for effects and lighting outdoors, then this IP65-rated Wash Beam Moving Head is the right choice. The warm white LED allows you to blend attractive warm pastel shades, and also delivers a wonderful warm white light for lighting people/objects/etc. The Cameo EVOS® W7 IP Wash Beam Moving Head with Single Pixel Control is devices, the Cameo EVOS® W7 IP offers a particularly high colour reproduction index. The warm white chip can be used to light people or objects - either with naturally warm white light or as mood lighting in pastel shades. This versatility results from the unique combination of a full-colour LED with a WW chip, which generates extremely clearly defined white tones with a CRI above Ra 90.
Providing individual control of all LEDs by means of Single Pixel Control, the Cameo EVOS® W7 IP Wash Beam Moving Head produces breath-taking pixel effects. The powerful luminous flux floods any event with warm, bright light in clearly defined colours and delivers generous coverage up to 540° horizontally (pan) and 270° vertically (tilt). Its versatility is further enhanced by an impressive zoom range of 4.5° to 55°, which facilitates powerful beam and large-area wash effects.
Live broadcast images of your event are guaranteed to be flicker-free because the Wash Beam Moving Head's refresh rate can be adjusted in six stages between 800 Hz and a maximum of 25 kHz.
Software control via a network is highly flexible with DMX, RDM Art-Net3, sACN or KlingNet. Further effect devices in the network are looped through via 5-pin XLR sockets. Independent operation and mains-independent configuration in Auto Program and Static Mode are carried out via the 4 touch buttons with battery-powered graphic display. Preset colour filters allow problem-free use in combination with conventional headlamps.
Features
- Wash-Beam Moving Head with IP65 classification
- 19 x 40 W RGBWW LEDs
- Precise colour reproduction with CRI > Ra 90
- Individual control of all LEDs (Single Pixel Control)
- Zoom range of 4.5° to 34° (beam) / 7° to 55° (field)
- Adjustable refresh rate of between 800 Hz and 25 kHz
- Control via DMX, W-DMX, RDM Art-Net3, sACN or KlingNet
- 4 touch sensitive buttons
Specifications
- Product type: LED Moving Lights
- Type: Moving Head
- Colour spectrum: RGBWW
- Number of LEDs: 19
- LED type: 40 W RGBWW
- Refresh rate: 800 Hz, 1200 Hz, 2000 Hz, 3600 Hz, 12 kHz, 25 kHz - adjustable Hz
- Dispersion: Beam Angle: 4.5 ° - 34 °, Field Angle: 7 ° - 55 °
- DMX input: Network, XLR 5-pin male IP65
- DMX output: Network, XLR 5-pin female IP65
- DMX mode: 16-channel, 18-channel, 23-channel, 33-channel, 43-channel, 87-channel
- DMX Functions: Colour presets, Device Settings, Dimmer, Dimmer Fine, Effect patterns, Motion Macro, Pan/Tilt, Pan/Tilt fine, Patterns, Single Pixel Control, Strobe, Zoom, Zoom Fine
- Control: ArtNet 3, DMX, KlingNet, sACN, W-DMX
- PAN movement: 540 °
- TILT movement: 270 °
- Standalone modes: Art-Net3, DMX512, KlingNet, RDM enabled, sACN
- Controls: Encoder wheel
- Indicators: Backlit colour LCD display, Battery supply for mains-independent system settings (automatically rechargeable battery)
- Operating voltage: 100 V AC - 240 V AC, 50 - 60 Hz
- Power consumption: 900 W
- Fuse: T10AL 250 V
- Power connector: Neutrik TrueOne Input
- Housing material: Environment-friendly fire-retardant ABS, nylon and polycarbonat
- Cabinet colour: Black
- Protection class IP: IP65
- Luminous flux: 12500 lm
- Width: 400 mm
- Height: 569 mm
- Depth: 330 mm
- Weight: 25 kg
